HIGH QUALITY HYDRAULIC STEEL AT
A COMPETITIVE PRICE

MOTUS has been sourcing high quality steel for the production of our hydraulic cylinders since 1963! Tried and proven in New Zealand conditions you can be assured that our hand-picked steel is the best we can get our hands on! We have now made this available to you in a complete range: ‘off-the-shelf’ and ‘cut-to-length’ and at a fair and reasonable price.

FAST

We understand the need for urgency especially in breakdown situations. Repairs are needed fast so we offer a same day dispatch promise. Order before 3pm and we will have your steel dispatched the same day!

FAIR

We use a large amount of steel for our own hydraulic cylinder manufacturing so we are able to buy direct from the mill and offer this to our valued customers. Quality at a competitive price!

FRIENDLY

We are a family owned business specialising in hydraulic cylinders and parts and with that comes a level of commitment, continuity and friendly service. Integrity, both at a product and a service level are crucially important to us.

CHROME BAR STOCK LIST

Metric

DIAMETER METRIC KGS/ MTR 1045 38MnVS6 IH
12 0.888
16 1.578
20 2.466
25 3.853
30 5.549
32 6.613
35 7.552
36 7.990
40 9.864
45 12.484
50 15.413
55 18.649
60 22.194
63 24.469
65 26.047
70 30.209
75 34.678
80 39.456
85 44.542
90 49.937
95 54.86
100 61.650
105 67.969
110 74.597

Imperial

DIAMETER KGS/ MTR 1045 38MnVS6 IH
1/2" 0.994
5/8” 1.492
3/4" 2.237
7/8" 3.045
1" 3.977
1-1/8" 5.034
1-1/4" 6.215
1-3/8" (34.925)
1-1/2" 8.949
1-5/8" 10.503
1-3/4" 12.181
2" 15.910
2-1/4” 20.136
2-1/2” 24.859
2-3/4” 30.079
3” 35.797
3-1/2” 48.723
4” 63.639
4-1/2”

HONED CYLINDER TUBE

Metric

ID OD WT KGS/MTR
25 35 5 3.699
30 40 5 4.316
35 45 5 4.932
40 50 5 5.549
45 55 5 6.165
50 65 7.5 10.635
55 70 7.5 11.560
60 75 7.5 12.485
63 73 5 8.385
65 80 7.5 13.410
70 80 5 9.248
70 85 7.5 14.334
75 95 10 20.962
80 100 10 22.195
85 105 10 23.428
90 110 10 24.662
95 115 10 25.895
100 125 12.5 34.680
105 125 10 28.361
110 140 15 46.240
115 140 12.5 39.304
120 145 12.5 40.846
125 150 12.5 42.387
130 155 12.5 43.928
130 160 15 53.639
140 170 15 57.338
150 180 15 61.037
155 170 7.5 30.056
160 190 15 64.736
160 195 17.5 76.605
170 210 20 93.714
180 210 15 72.135
200 250 25 138.721
220 260 20 118.375
250 300 25 169.548

Imperial

ID (INCHES) OD WT KGS/MTR
38.1(1-1/2") 50.5 6.35 6.774
50.8(2") 63.5 6.35 8.950
57.15(2-1/4") 69.85 6.35 9.944
63.50(2-1/2") 76.20 6.35 10.939
69.85(2-3/4") 82.55 6.35 11.933
76.20(3") 88.9 6.35 12.927
76.2(3") 92.1 7.95 15.25
76.2(3") 101.6 12.7 18.92
82.55(3-1/4") 101.6 9.525 21.628
88.9(3-1/2") 101.6 6.35 14.916
88.9(3-1/2") 104.8 7.95 23.120
101.6(4") 117.5 7.95 16.905
101.6(4") 127 12.7 35.799
107.95(4.25") 127 9.525 27.595
114.3 (4-1/2") 139.7 12.7 39.777
127 (5") 152.4 12.7 43.754
139.7 (5.5") 165.1 12.7 47.732
152.4 (6") 171.45 9.525 38.036
177.8 (7") 203.2 12.7 59.665
203.2 (8") 228.6 12.7 67.620
228.6 (9") 254 12.7 75.575

CHROME BAR
TECHNICAL INFORMATION

Specifications

  • 20-micron miniumum chrome layer depth.
  • 1-3mm induction hardened depth, to 55-60 HRC Hardness (38MnVS6)
  • Corrosion level 10 at 120 hours, Level 9 at 312 hours using ISO 9227 evaluated at ISO 10289 NSS.
  • OD tolerance is f7.
  • Surface roughness is Ra 0.07 – 0.2µm,
  • Straightness 0.2mm per metre max.
  • 600-800 (1045) – 850-1000 (38MnVS6) (N/mm² or MPa) Tensile.
  • Surface Hardness is HV900 or 66 HRC non IH.
  • Surface Hardness is HV750 or 60 HRC IH.

Benefits

  • Excellent machinability.
  • Excellent weldability.
  • High tensile premium material (38MnVS6).
  • Ideal for earthmoving or forestry application in IH (38MnVS6).

HONED HYDRAULIC TUBE
TECHNICAL INFORMATION

Specifications

  • Straightness tolerance of 0.5mm per metre maximum.
  • iD tolerance: H7.
  • 700-800 (N/mm² or MPa) Tensile.
  • Internal roughness: Ra 0.2 µm to Ra 0.4 µm.
  • Grade: EN10305-2

Benefits

  • Excellent machinability.
  • Excellent weldability.
  • Premium quality welded seam tube.
  • No steady tracking required.
  • Good concentricity.
